KRAMER 4x1 USB Switcher Transmitter [SWT3-41-U-T]

Spesifikasi Produk

Deskripsi

Hosts: 2 USB 3.2 & PD 3.0 Hosts: On USB type–C female connectors, 2 USB 3.2 Hosts: On USB–B female connectors | Devices: 3 USB 3.2 Devices: On USB–A female connectors, 1 USB 3.2 Device: On a USB type–C female connector | Ports: 1 PoE-accepting Ethernet: On an RJ–45 female connector for LAN connection and extension over CAT links, 1 RS–232: On a 3–pin terminal block, 2 GPIO: On a 2–pin terminal block | USB 3.2 Data Rate: Up to 10Gbps | Integrated USB Hubs: 2 [device 1 & 2 ports] or 1 [other device ports] | Standards Compliance: USB 3.2 GEN 2, 2.0 and 1.1 | Power Source: 20V DC: 6A (included) | Power Consumption: 20V DC: 3.8A | Max. Power: 20V DC: 80W | PoE Consumption: 370mA | PoE Max. Power: 20W | USB-C Host Charging Max. Power: 60W | Max. Total Current: 2A | Inputs: 1 Stereo Analog Balanced Audio: On a 5–pin terminal block for audio extension | Outputs: 2 CAT: On an RJ–45 female connector for extension line | Extended USB: Data Rate: Up to 480Mbps, Transmitted Data Bandwidth: Up to 300Mbps, Standards Compliance: 2.0 and 1.1 USB | Extension Line: Reach: Up to 100m (330ft) | Extended Ethernet: Data Rate: Up to 100Mbps
