Spesifikasi Produk
Deskripsi
Image Sensor 1/3" progressive scan CMOS Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR Image EnhancementHLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus High quality imaging with 4 MP resolution 4x optical zoom allows for closer viewing of subjects in expansive areas Digital Zoom 16× Max. Resolution 2560 × 1440 Material Aluminum alloy, PC, PC+ABS Protection Level IP66 Standard, IK 10, Surge Protection, ±2kV Line to Gnd, ±1kV Line to Line, IEC61000-4-5 Working Temperature -20°C to 60°C (-4°F to 140°F
CCTV :
Image Sensor 1/3" progressive scan CMOS
Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON),B/W: 0.001 Lux @(F1.6, AGC ON),0 Lux with IR
Image EnhancementHLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus
High quality imaging with 4 MP resolution
4x optical zoom allows for closer viewing of subjects in expansive areas
Digital Zoom 16×
Max. Resolution 2560 × 1440
Material Aluminum alloy, PC, PC+ABS
Protection Level IP66 Standard, IK 10, Surge Protection, ±2kV Line to Gnd, ±1kV Line to Line, IEC61000-4-5
Working Temperature -20°C to 60°C (-4°F to 140°F
NVR :
Powered by eSSD technology
Low power consumption
Up to 40 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
IP Video Input 4-ch
Working Temperature-10 °C to 50 °C (14 °F to 122 °F)
Power Supply :
Solar Panel 200 WP include bracket
Solar Charge Controller (MPPT) 12/24Volt
Step Up
Baterai/Aki Voltase 12 Volt, Capacity 120 Ah (ampere-hour)
Enclosure dan Pengaman (Panel Box, Kerangkeng/Teralis Pengaman, Conduit, dan Kunci Pengaman)
Modem :
Mobile module : 4G LTE, 3G, 2G
Wireless mode : 802.11b/g/n (Wi-Fi 4), Access Point (AP), Station (STA)
Wi-Fi users : Up to 50 simultaneous connections
Ethernet : 1 x WAN port, 1 x LAN port 10/100 Mbps compliance with IEEE 802.3
HikCentral Base License :
CCTV Software Platform integrating and managing security systems (Lisensi HikCentral Base Professional )
HikCentral Base Expansion Channels License :
CCTV Software Platform integrating and managing security systems (Lisensi HikCentral Base Expansion Channels)
