MESIN CNC MILLING VMC 320
Spesifikasi Produk
| SKU | ACMVMC002320 |
| Garansi | 1 TAHUN |
| Dimensi | 150cm x 140cm x 200cm |
| Berat | 1.500kg |
| Produk | Non-UMKM |
| Buatan | Dalam Negri |
| KBKI | - |
| Sertifikat TKDN | |
| TKDN | 0.00% |
| BMP | 0.00% |
| TKDN + BMP | 0% |
Deskripsi
Spesifikasi Produk: Mesin cnc milling VMC 320, UKURAN MEJA KERJA 700X210 MM, T slot (width* qty * space between) : 11mmx4pcx45mm Max loading weight on worktable : 200KG X-Axis travel: 365 MM Y-Axis travel : 260 MM Z-Axis travel 440MM Distance between spindle nose and table : 70-510 (mm) Distance between spindle center and column :290mm Spindle taper : 30 BT Max loading weight on worktable : 200 KG Max. spindle speed :8000rpm/min Spindle motor power : 2.2/3.7 kw Feeding motor power X Axis : 1,8 kw Feeding motor power: Y Axis : 1,8 kw Feeding motor power: Z Axis : 1,8kw Rapid feeding speed: X,Y,Z axis : 12 m/min Feeding speed : 0-4000 mm/min Min. set unit : 0.001 mm Max. size of tool : Ф60х175 mm ATC capacity : 8 tools position Max. loading weight of tools : 3.5 kg N.W. : 1300kg Packing size (L x Wx H) : 1400x1500x2000 (mm) Keterangan Lainnya: INCLUDE PPN Fungsi: untuk proses kerja milling dengan pengkontrolan numerik Ketersediaan Suku Cadang: YA
