Spesifikasi Produk
| SKU |
|
| Garansi |
1 TAHUN |
| Dimensi |
35cm x 45cm x 15cm |
| Berat |
3kg |
| Produk |
Non-UMKM |
| Buatan |
Luar Negri |
| KBKI |
- |
| Sertifikat TKDN |
|
| TKDN |
0.00% |
| BMP |
0.00% |
| TKDN + BMP |
0% |
Deskripsi
DESKRIPSI :- Koneksi : Bi-directional parallel interface (IEEE-1284 nibble mode supported) USB 2.0 Full-Speed Serial- Kecepatan : 347 / 357 / 390 cps- Driver : Windows Microsoft Windows 2000 / XP / 7, Microsoft Windows Vista- Dimensi : 35.5 x 30 x 16cm (LxWxH) - Pixel Resolutions Max : 9 pin, 160 columns max, up to 240 x 216 dp
Teknologi Pencetakan:
Metode Cetak:
Impact dot matrix
Panel Kontrol:
4 switches and 5 LEDs
Arah Cetak:
Bi-direction with logic seeking
Jumlah Pin Pada Kepala:
9 pins
Kode Kontrol:
ESC/P and IBM PPDS emulation
Number of Pins:
9
Kecepatan Cetak:
Draf Kecepatan Tinggi:
(10 / 12 / 15 cpi): 347 / 357 / 390 cps
(Condensed, 17 / 20 cpi): 383 / 298 cps
Draf:
(10 / 12 / 15 cpi): 260 / 312 / 223 cps
(Condensed, 17 / 20 cpi): 222 / 260 cps
(Emphasized, 10 cpi): 130 cps
NLQ:
(10 / 12 / 15 / 17 / 20 cpi): 65 / 78 / 55 / 47 / 56 cps
Reliabilitas:
Printhead Life:
Approx. 400 million strokes/wire
Volume Cetak Rata-rata Antara Kegagalan (Mean Print Volume Between Failure / MVBF):
Approx. 20 million lines (Except print head)
Waktu Rata-rata Antara Kegagalan (MTBF):
Approx. 10,000 POH (25% Duty)
Karakteristik Cetak:
Set Karakter:
Italic table, PC437 (US Standard Europe), PC850 (Multilingual), PC860 (Portugese), PC861 (Icelandic), PC863 (Canadian French), PC865 (Nordic), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15
Font Bitmap:
Epson Draft: 10, 12, 15 cpi; Epson Roman & Sans Serif: 10, 12, 15 cpi, Proportional, Epson OCR-B
Barcode:
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet
Jalur Kertas:
Penyisipan Manual:
Rear in, Top out
Push Tractor:
Rear in, Top out
Media Kertas:
Lembar Potong (Lembar Tunggal):
Length: 100 ~ 364mm (3.9 ~ 14.3")
Width: 100 ~ 257mm (3.9 ~ 10.1")
Thickness: 0.065 ~ 0.14mm (0.0025 ~ 0.0055")
Lembar Potong (Bentuk Multibagian):
Length: 100 ~ 364mm (3.9 ~ 14.3")
Width: 100 ~ 257mm (3.9 ~ 10.1")
Thickness: 0.12 ~ 0.39mm (0.0047 ~ 0.015") (Total)
Kertas Kontinu (Lembar Tunggal / Multibagian):
Length: 101.6 ~ 558.8mm (4.0 ~ 22.0")
Width: 101.6 ~ 254.0mm 4.0 ~ 10.0")
Thickness: 0.065 ~ 0.39mm (0.0025 ~ 0.015") (Total)
Amplop (No.6):
Length: 92mm (3.6")
Width: 165mm (6.5")
Thickness: 0.16 ~ 0.52mm (0.0063 ~ 0,0205") (Total)
Amplop (No.10):
Length: 105mm (4.1")
Width: 241mm (9.5")
Thickness: 0.16 ~ 0.52mm (0.0063 ~ 0.0205") (Total)
Kertas Gulung:
Width: 216mm (8.5")
Thickness: 0.07 ~ 0.09mm (0.0028 ~ 0.0035")
Sistem Operasi dan Aplikasi yang Didukung:
Operasi Yang Didukung:
Microsoft® Windows® 2000 / XP / Vista / 7 / 8 / 8.1 / 10
Dimensi Dan Berat:
Dimensi Keseluruhan (L x D x T):
362 x 275 x 154 mm
Berat:
Approx. 4.1 kg
Bahan Habis Pakai :
Kartrid Pita Hitam:
Ribbon Life: Approx. 4.0 million characters (Draft 10 cpi, 14 dots/character)
Kondisi Lingkungan (Pengoperasian):
Suhu:
5 ~ 35°C
Kelembapan:
10 ~ 80 % RH
Kebisingan Akustik:
Kebisingan Akustik:
Approx. 53 dB(A) (ISO 7779 pattern)
Buffer Input Data:
Buffer Input Data:
128KB
Antarmuka:
Standar:
Bi-directional parallel (IEEE-1284 nibble mode supported)
USB 2.0 Full-Speed
Serial
Ribbon Cartridge:
Standar:
Fabric Ribbon Cartridge (Black) - C13S015632
Ribbon Life:
Approx. 4.0 million characters (Draft 10 cpi, 14 dots/character
