MCCB 3p 60a Schneider

Spesifikasi Produk

Deskripsi

MCCB Schneider Easypact EZC100F 3 Phase 60 Ampere Spesifikasi : - Tipe : EZC100F3060 - Device Application : Distribution - Poles Description : 3P - Number of Protected Poles : 3 - Network Type : AC & DC - Network Frequency : 50/60 Hz - [In] Rated Current : 100 A at 40°C - [Ui] Rated Insulation Voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 - [Uimp] Rated Impulse Withstand Voltage : 6 kV conforming to IEC 60947-2 - ############################## - [Ue] Rated Operational Voltage : - ~550 V AC 50/60 Hz conforming to IEC 60947-2 - ~250 V DC conforming to IEC 60947-2 - ############################## - Breaking Capacity : - ~25 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2 - ~25 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 - ~5 kA Icu at 125 V DC 1P conforming to IEC 60947-2 - ~5 kA Icu at 250 V DC 2P conforming to IEC 60947-2 - ~5 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 - ~10 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 - ~10 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 - ~7.5 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 - ############################### - Control Type : Toggle - Mounting Mode : Fixed - Mounting Support : Backplate - Height : 130mm - Width : 75mm - Depth : 60mm
